Frequency Conversion Technology Adopted: The integrated air compressor features a maintenance-free design for reduced operational costs.
Minimum maintenance (reduced by 80%):
Maintenance-free & Oil-free Air Compressor: No lubricating oil required, with both compressor and oxygen generator pressure < 1bar for safe and stable operation.
Minimum operation:
Ultra-low Maintenance Cost + 50%+ Energy Savings (as low as 0.7KWH per unit)
Fully automatic operation & diagnosis, minimizing manual intervention.
Quick installation in 20 minutes:
Skid-mounted Design: The system replaces the cumbersome pipeline network with a compact [2 solenoid valves + servo motors] configuration, boasting an ultra-simplified structure.
Technical specification
| Stats | 10NM³/h | 20NM³/h |
30NM³/h |
| Average power | 7kW | 10kW | 10kW |
| Energy consumption | 0.65kWh/Nm³ | 0.7kWh/Nm³ | 0.7kWh/Nm³ |
| Noise | ＜80dB | ＜80dB | ＜80dB |
| Power source | 3N~380V | 3N~380V | 3N~380V |
| Size | 4700*1600*1900mm | 4700*1600*1900mm | 4980*1720*2160mm |
| Machine weight | 1960kg | 2065kg | 2475kg |
| Outlet pressure | 4-8bar | ||
| Install | 4980*1720*2160mm4980*1720*2160mm | ||
Product introduction
The VSA oxygen generator excels in energy conservation, efficiency, reliability, ease of maintenance, installation, cost-effectiveness, safety and environmental friendliness. It offers 10 key advantages:
1. Ultra-simplified Structure: Only 3 core components (air compressor, oxygen generation main unit, oxygen compressor) minimize maintenance work/costs, optimize processes, and ensure superior reliability and higher efficiency.
2. Outstanding Energy Savings: Low-pressure operation cuts energy consumption, and the simplified structure further reduces energy loss for top-tier energy efficiency.
3. Quick Installation: Integrated modular design of the 3 core components enables fast, hassle-free setup.
4. Low-pressure Operation: Air & molecular sieve adsorption pressure < 0.1 MPa (1/10 of traditional PSA pressure), minimizing molecular sieve crushing risk.
5. Oil-free Oxygen Production: Oil-free compressed air prevents molecular sieve contamination and saves oil treatment maintenance costs.
6. Extended Molecular Sieve Lifespan: Addresses the 3 key factors (water, oil, pressure) affecting sieve life, reducing risks of powdering, oil contamination and water-induced softening failure.
7. No Pressure Vessels Needed: Simplifies operation & management, boosting safety.
8. Eco-friendly Performance: No oil treatment system required, producing oil-free oxygen for safe use and environmental sustainability.
9. Low Overall Costs: 40% lower unit oxygen production cost, 50% reduced management cost, and over 60% annual maintenance cost savings.
10. Highly Intelligent Operation: Automatically adjusts parameters based on environment, working frequency and usage habits; predicts and handles anomalies/maintenance needs to ensure peak efficiency, cutting management costs and complexity for hospitals while guaranteeing efficiency, lifespan and safety.
Product features
VSA (Vacuum Pressure Swing Adsorption) Oxygen Generator extracts oxygen from air via vacuum desorption based on PSA principles.
Oil-free system, no valve group required
Energy-efficient: ≤1 KWh per Nm³ oxygen
Highly integrated, compact size for easy transportation & quick installation
Low maintenance
High reliability with 10+ years lifespan
Fully automatic operation
Featuring an ultra-simplified structure with only 3 core units: air treatment unit, nitrogen-oxygen separation unit, and oxygen treatment unit.
Product applications
Application Scenarios: Medical institutions, field hospitals, energy-saving projects, environmental protection initiatives, high-altitude areas, high oxygen demand sites, clinics, quick-installation required locations, space-constrained areas, high-pressure oxygen cylinder filling stations.
We are dedicated to delivering science-backed solutions tailored to your application scenarios and needs, bringing convenience, cost-effectiveness, eco-friendliness and sustainability to your oxygen supply.
FAQ
How much does a VSA oxygen concentrator cost?
Pricing of VSA oxygen concentrators varies by model and production capacity. As a direct manufacturer, we offer highly competitive prices-welcome to contact us for a detailed quote.
How to choose the right VSA oxygen concentrator?
When selecting a VSA oxygen concentrator, factors like oxygen demand, purity requirements and usage environment should be taken into account. Our technical team provides professional recommendations to help you choose the best-fit product.
What should we pay attention to when maintaining and maintaining the VSA oxygen concentrator?
Regular filter inspection & cleaning, pressure and flow monitoring are key to VSA oxygen concentrator maintenance. As a professional manufacturer, we provide comprehensive maintenance guidance.
After purchasing a VSA oxygen concentrator, how to ensure safe use?
Safe operation of the VSA oxygen concentrator requires strict compliance with operating procedures and safety guidelines. As a professional oxygen concentrator manufacturer, we provide detailed instructions and training to ensure safe and standardized equipment usage.
